Extra High Power Lumen Tri-Proof Low Bay

Linear Light Series

A single engineered light source — EHPL — built into a tri-proof linear low-bay fixture: waterproof, corrosion-proof, and explosion-proof, for the harshest industrial floors.

Linear Light Series — EHPL tri-proof low bay fixture LVD-LB0X SERIES
160–200lm/W
EFFICACY
40–300W
POWER RANGE
60,000+ hrs
LIFESPAN
IP65 / IK10
INGRESS & IMPACT RATING

Specification

Unit CodesLVD-LB0X, 40–300W
Power Range40W – 300W
Luminous Efficacy160 – 200 lm/W
Input Voltage100–277V
CCT3000K – 5700K
Power Factor>0.95
CRIRa70 – Ra80
MaterialHigh Grade Aluminium Heat Sink
Operating Temp.-40°C to 50°C
InstallationBracket Mounted / Suspended Mounted
IP RateIP65
IK RateIK10
Beam Angle60° / 90° / 120° / Asymmetric 15°
Dimensions1–5 ft (1′: 40–60W · 2′: 80–120W · 3′: 150–180W · 4′: 200–240W · 5′: 250–300W)
Sensor & DimmingMotion & Light Sensor · 0–10V / DALI Dimming
Lifespan> 60,000 hours

Features

  • Tri-Proof construction — waterproof, corrosion-proof & explosion-proof
  • High luminous efficacy: 160–200 lm/W
  • IK10 impact resistance alongside IP65 ingress protection
  • 0–10V / DALI dimming, plus motion & light sensor integration
  • Long lifespan — over 60,000 hours of operation
  • Modular 1–5 ft lengths matched to wattage, for bracket or suspended mounting
  • Selectable beam angle: 60°, 90°, 120°, or asymmetric 15°
